New Life For Mobile Rack
A 17-year-old mobile racking system from thyssenkrupp Materials Hungary was brought back up to the current state of the art through retrofitting As part of a comprehensive modernisation, OHRA replaced damaged mechanical parts of the traversing carriages and modernised the entire electrical engineering. The retrofitting ensures that the plant will continue to operate with a high level of availability in the future, so that thyssenkrupp Materials can continue to supply its customers with goods reliably and on time.
Spare Parts No Longer Available
In Hungary, thyssenkrupp Materials Hungary is one of the leading trading companies for steel, light metal, non-ferrous metal and plastic materials. In order to have direct access to a large number of different sheet metal coils with high storage capacity, the company installed pallet racks mounted on traversing carriages in 2005. But after 17 years in service, the supply of spare parts is proving increasingly difficult. Many components of the control and switchgear system of the mobile racking were discontinued or no longer available. However, as the steel structure still met all requirements, thyssenkrupp Materials Hungary decided to retrofit the racking system. As OHRA had already planned and installed a mobile cantilever racking system at thyssenkrupp Materials Hungary, the specialist for heavy-duty storage technology was also commissioned to modernise the coil mobile racking system - even though this was installed by a third-party supplier at the time.
Completely New Control Cabinets
In the first step, OHRA replaced all wheels and wheel bearings - a total of 560 each - of the transfer trolleys. In the second step, the control cabinets of the plant were completely renewed, including the cabling - in the meantime, obsolete components had been installed for which both spare parts and service were no longer available. Today, all functions and diagnostics are controlled via an intuitive colour touch screen. A soft-start function now ensures gentle starting and braking of the transfer carriages - this reduces wear and protects the stored goods. In order to continue to meet safety requirements, the safety system was also updated. Among other things, the entire racking block as well as each transfer trolley was equipped with self-checking optical sensors at the front and rear.
Safe And Reliable
The comprehensive modernisation measures were completed within two weeks. Through the retrofit, OHRA has ensured that the mobile racking system can reliably perform its service for many more years. With the modern control system and a state-of-the-art safety system, the modernised system meets the same requirements as a new racking system - but only requires a fraction of the investment.
